Aim-TTi TGA1241 TGA1241 Arbitrary Waveform Generator 16MHz [TGA1241]; 387-4905
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Frequency | 16MHz |
| Minimum Frequency | 0.1 mHz |
| Maximum Frequency Triangle Ramps | 100kHz |
| Minimum Frequency Triangle Ramps | 0.1MHz |
| Maximum Sampling Frequency | 40Msps |
| Maximum Pulse Train Repetition Rate | 100ns |
| Minimum Pulse Train Repetition Rate | 100s |
| Resolution | 3 Digit |
| Pulse Resolution | 4Digit |
| Maximum Pulse Delay | +99.99s |
| Minimum Pulse Delay | -99.99s |
| Maximum Pulse Width | 100s |
| Minimum Pulse Width | 100ns |
| Arbitrary Waveforms | Yes |
| Maximum Operating Temperature | +40°C |
| Interface Type | GPIB, RS232 |
| Minimum Operating Temperature | +5°C |
| Maximum Storage | 100 |
| Height | 130mm |
| Width | 212mm |
| Maximum Output Amplitude | 20V Pk-Pk |
| Weight | 4.1kg |
| Dimensions | 335 x 212 x 130mm |
| Sweep | Continuous, Linear, Logarithmic, Triggered |
| Waveform Memory per Channel | 64k points |
| Model Number p | TGA1241 |
| Plug Type | Type C - European Plug, Type G - British 3-pin |
| Rise - Fall Time | 25ns |
| Length | 335mm |
| Display Type | 20 Char x 4 Rows |
| Data Entry | Keyboard |
| Inputs | Hold, Modulation In, Reference In, Sum In, Trig In |
