Diodes Inc ZTX855 NPN Transistor, 4 A, 150 V, 3-Pin TO-92 [ZTX855]; 165-8489
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Transistor Type | NPN |
| Maximum DC Collector Current | 0.166666666666667 |
| Maximum Collector Emitter Voltage | 150 V |
| Package Type | TO-92 |
| Mounting Type | Through Hole |
| Maximum Power Dissipation | 1.58 W |
| Minimum DC Current Gain | 35 |
| Transistor Configuration | Single |
| Maximum Collector Base Voltage | 250 V |
| Maximum Emitter Base Voltage | 6 V |
| Maximum Operating Frequency | 100 MHz |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Width | 2.41mm |
| Maximum Base Emitter Saturation Voltage | 1100 mV |
| Length | 4.77mm |
| Height | 4.01mm |
| Maximum Collector Emitter Saturation Voltage | 260 mV |
| Maximum Operating Temperature | +200 °C |
| Dimensions | 4.77 x 2.41 x 4.01mm |
| Minimum Operating Temperature | -55 °C |
