Dây rút Panduit [B4M2S-TL0]

Name: Dây rút Panduit [B4M2S-TL0]
Brand: Panduit
SKU: PAB621
Availability: InStock

Mã kho: PAB621

Mã nhà sản xuất: B4M2S-TL0

Tên nhà sản xuất: Panduit

0₫ - 0₫

0₫

0₫ - 0₫

0₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit B4M2S-TL0

MÔ TẢ SẢN PHẨM

Dome-Top® barb ty marker tie, wrap, standard cross section, 8.0 (203mm) length, 2.47 x .91 (62.7 x 23.1mm) marker write-on area, weather resistant nylon 6.6, black.

_THÔNG SỐ KỸ THUẬT:

Product Type	Cable Tie
Sub Brand	Dome-Top®
Color	Black
Environment	Outdoor
For Use With	Bundles
Marker Type	Wrap
Material	Nylon 6.6
Maximum Bundle Diameter (In.)	2
Maximum Bundle Diameter (mm)	51
Maximum Installation Temperature (°C)	0
Maximum Installation Temperature (°F)	32
Maximum Operating Temperature (°C)	85
Maximum Operating Temperature (°F)	185
Minimum Bundle Diameter (In.)	0.37
Minimum Bundle Diameter (mm)	9.5
Minimum Installation Temperature (°C)	-20
Minimum Installation Temperature (°F)	-4
Minimum Loop Tensile Strength (N)	222
Minimum Loop Tensile Strength (lb)	50
Minimum Operating Temperature (°C)	-60
Minimum Operating Temperature (°F)	-70
Overall Length (In.)	8
Overall Length (mm)	203
Body Width (In.)	0.185
Body Width (mm)	4.7
Body Thickness (In.)	0.45
Body Thickness (mm)	1.2
Resistance Properties	UV Resistant
Standards Met	UL 62275 Compliant (Type 1, 11),CE Compliant,RoHS Compliant
Application	General
