Dây rút Panduit [PLT1M-L4Y]

Name: Dây rút Panduit [PLT1M-L4Y]
Brand: Panduit
SKU: PAA573
Availability: InStock

Mã kho: PAA573

Mã nhà sản xuất: PLT1M-L4Y

Tên nhà sản xuất: Panduit

0₫ - 0₫

0₫

0₫ - 0₫

0₫

Pan-Ty® locking tie, miniature cross section, 4.0" (102mm) length, nylon 6.6, yellow.

Product Type	Cable Tie
Color	Yellow
Environment	Indoor
Sub Brand	Pan-Ty®
For Use With	GTS-E, GS2B-E, PTS
Material	Nylon 6.6
Resistance Properties	NA
Maximum Bundle Diameter (In.)	0.87
Maximum Bundle Diameter (mm)	22.1
Maximum Installation Temperature (°F)	32
Maximum Operating Temperature (°C)	85
Maximum Operating Temperature (°F)	185
Minimum Bundle Diameter (In.)	0.06
Minimum Bundle Diameter (mm)	1.5
Minimum Installation Temperature (°C)	-20
Minimum Installation Temperature (°F)	-4
Minimum Loop Tensile Strength (N)	80
Minimum Loop Tensile Strength (lb)	18
Minimum Operating Temperature (°C)	-60
Minimum Operating Temperature (°F)	-76
Overall Length (In.)	4
Overall Length (mm)	102
Body Width (In.)	0.1
Body Width (mm)	2.5
Body Thickness (In.)	0.036
Body Thickness (mm)	0.9
Standards Met	CSA Certified, UL Recognized (File #E56854), UL 62275 Compliant (Type 2, 21), RoHS Complaint
Part Features	One-piece, all nylon cable tie accommodate a maxinum bundle diamter of 0.82" (21mm).
