Dây rút Panduit [PLT1M-XMR7]

Name: Dây rút Panduit [PLT1M-XMR7]
Brand: Panduit
SKU: PAB615
Availability: InStock

Mã kho: PAB615

Mã nhà sản xuất: PLT1M-XMR7

Tên nhà sản xuất: Panduit

0₫ - 0₫

0₫

0₫ - 0₫

0₫

Reel-Fed cable tie for PAT1M system, miniature cross section, 4.0 (102mm) length, nylon 6.6, purple.

Application	Used For PAT1M System
Product Type	Reel-Fed Cable Tie
Color	Purple
Sub Brand	Pan-Ty®
Environment	Plenum or Air Handling Spaces
For Use With	PAT1M System
Material	Nylon 6.6
Maximum Bundle Diameter (In.)	0.82
Maximum Bundle Diameter (mm)	20.8
Maximum Operating Temperature (°C)	85
Maximum Operating Temperature (°F)	185
Minimum Bundle Diameter (In.)	0.02
Minimum Bundle Diameter (mm)	0.5
Minimum Loop Tensile Strength (N)	80
Minimum Loop Tensile Strength (lb)	18
Minimum Operating Temperature (°C)	-60
Minimum Operating Temperature (°F)	-76
Overall Length (In.)	4
Overall Length (mm)	102
Body Width (In.)	0.1
Body Width (mm)	2.5
Body Thickness (In.)	0.036
Body Thickness (mm)	0.9
Resistance Properties	NA
Standards Met	UL Listed, UL Recognized, CSA Certified, CE Compliant, RoHS Compliant
Military Cross Reference Number	MS3367-4-7
Number of Ties per Reel	5000
