Panduit MS Strapping, 316 SS, .75" (19.0mm) W, 51.0" (991mm) L, .030" (.76mm) thk [MS14W75T30-Q6]; PAN392

Name: Panduit MS Strapping, 316 SS, .75" (19.0mm) W, 51.0" (991mm) L, .030" (.76mm) thk [MS14W75T30-Q6]; PAN392
Brand: Panduit
SKU: PAN392
Price: 646340.0 VND
Availability: InStock

Mã kho: PAN392

Mã nhà sản xuất: MS14W75T30-Q6

Tên nhà sản xuất: Panduit

646.340₫ - 646.340₫

646.340₫

646.340₫ - 646.340₫

646.340₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Routing Management Protection / Cable Cleats / Cable Cleats: Panduit MS14W75T30-Q6

MÔ TẢ SẢN PHẨM

The MS14W75T30-Q6 Discrete Length Stainless Steel Buckle Strap cable cleat is an effective option for protecting against high short circuit fault current requirements in harsh environments. The variable design is compatible with quad, trefoil, and multicore cables and certified to IEC61914:2015, tes

_THÔNG SỐ KỸ THUẬT:

Application	Corrosive Environment
Product Type	Strapping
Color	Natural
Environment	Indoor and Outdoor
Finish/Coating	NA
For Use With	BT75SDT
Material	316 Stainless Steel
Maximum Bundle Diameter (In.)	14
Maximum Bundle Diameter (mm)	356
Maximum Installation Temperature (°C)	538
Maximum Installation Temperature (°F)	1000
Minimum Installation Temperature (°C)	-60
Minimum Installation Temperature (°F)	-76
Maximum Operating Temperature (°C)	538
Maximum Operating Temperature (°F)	1000
Minimum Operating Temperature (°C)	-60
Minimum Operating Temperature (°F)	-76
Minimum Loop Tensile Strength (N)	10656
Minimum Loop Tensile Strength (lb)	2400
Overall Length (In.)	50.1
Overall Length (mm)	1273
Overall Width (In.)	0.75
Overall Width (mm)	19.1
Resistance Properties	NA
Standards Met	RoHS Compliant,UL E56854, UV Resistant
Strap Breaking Strength (N)	10656
Strap Breaking Strength (lb)	2400
Overall Thickness (In.)	0.03
Overall Thickness (mm)	0.8
Part Features	Fold over design provides high-retained tension in mechanical fastening and cable bundling applications; After tensioning, cut end is locked inside low profile buckle – no sharp edges; Can be used in a wide range of applications including direct burial; Smooth surfaces and rounded edges assures cable protection and worker safety.
