Panduit 8 AWG (Str.) - 4 AWG (Str.) Bronze Ground Clamp Connector, 3/8" Bolt, 2 Piece Clamp & 1 Bolt [GL4-38-X]; PAL682

Name: Panduit 8 AWG (Str.) - 4 AWG (Str.) Bronze Ground Clamp Connector, 3/8" Bolt, 2 Piece Clamp & 1 Bolt [GL4-38-X]; PAL682
Brand: Panduit
SKU: PAL682
Availability: InStock

Mã kho: PAL682

Mã nhà sản xuất: GL4-38-X

Tên nhà sản xuất: Panduit

0₫ - 0₫

0₫

0₫ - 0₫

0₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Grounding Bonding / Grounding Mechanical Connectors / Flat Surface Grounding Clamps: Panduit GL4-38-X

MÔ TẢ SẢN PHẨM

8 AWG (Str.) - 4 AWG (Str.) Bronze Ground Clamp Connector, 3/8" Bolt, 2 Piece Clamp & 1 Bolt

_THÔNG SỐ KỸ THUẬT:

Sub Brand	NA
Product Type	Grounding Clamp
Material	Copper Alloy
Maximum Compatible Conductor Size (AWG SOL)	NA
Maximum Compatible Conductor Size (AWG STR)	4
Maximum Compatible Conductor Size (AWG)	NA
Hex Size (In.)	NA
Minimum Compatible Conductor Size (AWG SOL)	NA
Minimum Compatible Conductor Size (AWG STR)	8
Minimum Compatible Conductor Size (AWG)	NA
Overall Length (In.)	1.46
Overall Length (mm)	37
Overall Width (In.)	1.24
Overall Width (mm)	32
Overall Height (In.)	1.75
Overall Height (mm)	45
Standards Met	cULus Listed to UL467/CSA 22.2 No.4 for Direct Burial Grounding
Application	Utility/Ground Grid

Panduit 8 AWG (Str.) - 4 AWG (Str.) Bronze Ground Clamp Connector, 3/8" Bolt, 2 Piece Clamp & 1 Bolt [GL4-38-X]; PAL682
