Grounding Bonding / Grounding Mechanical Connectors / U Bolt Grounding Clamps: Panduit GR125-10-1

MÔ TẢ SẢN PHẨM

Pipe Clamp; Braided Strap: 1" x 1/8" to Pipe or Rod; Direct Burial, 1-1/4" Pipe

_THÔNG SỐ KỸ THUẬT:

Material	Bronze
Maximum Copper Conductor Size (AWG STR)	2
Minimum Copper Conductor Size (AWG STR)	2
Iron Pipe Size (In.)	1.25
Number Of Wires	1
Overall Length (In.)	3
Overall Length (mm)	76.2
Overall Width (In.)	1.38
Overall Width (mm)	35.052
Overall Height (In.)	3.5
Overall Height (mm)	88.9
Bolt Diameter (In.)	3/8
Clamp Tightening Torque (in·lb)	180
Hex Size (In.)	9/16
Application	Utility/Ground Grid
Standards Met	cULus Listed to UL 467 for Direct Burial Grounding
Product Type	Ground Clamp
