Sifam Tinsley RN30B-102900E8, 2 Channel, Chart Recorder Measures Current, Humidity, Resistance, Temperature, Voltage [N30B-102900U0]; 886-1777
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Parameter Measured | Current, Humidity, Resistance, Temperature, Voltage |
| Maximum Temperature Measurement | +55 °C |
| Maximum Humidity Measurement | 95%RH |
| Maximum Current Measurement | 0.5 (Relay) A, 20 (Analogue) mA, 30 (OC Output) mA |
| Maximum Voltage Measurement | 10 (Analogue) V ac, 30 (OC Output) V dc, 250 (Relay) V ac |
| Maximum Resistance Measurement | ≤500 (Current Programmable) Ω, ≥500 (Voltage Programmable) Ω |
| Recorder Input Type | Current, Humidity, Resistance, Temperature, Voltage |
| Number of Inputs | 2 |
| Number of Outputs | 3 |
| IP Rating | IP10, IP65 |
| Height | 48mm |
| Maximum Operating Voltage | 253 V ac, 320 V dc |
| Width | 93mm |
| Dimensions | 96 x 93 x 48mm |
| Power Source | Mains |
| Length | 96mm |
| Model Number p | RN30B-102900E8 |
| Best Current Measurement Accuracy | 0.002 |
| Weight | <200g |
| Best Voltage Measurement Accuracy | 0.002 |
| Best Resistance Measurement Accuracy | 0.002 |
| Minimum Operating Voltage | 85 V ac, 90 V dc |
