The thermal transfer military grade heat-shrink label in yellow is single sided with a 3/8" (9.525mm) diameter and made of 3:1 flattened polyolefin. It is .5" (12.7mm) wide and .64" (16.3mm) high. The heat-shrink sleeve is designed to provide a clear, rel

Name: The thermal transfer military grade heat-shrink label in yellow is single sided with a 3/8" (9.525mm) diameter and made of 3:1 flattened polyolefin. It is .5" (12.7mm) wide and .64" (16.3mm) high. The heat-shrink sleeve is designed to provide a clear, rel
Brand: Panduit
SKU: PAL982
Price: 25542240.0 VND
Availability: InStock

Mã kho: PAL982

Tên nhà sản xuất: Panduit

25.542.240₫ - 25.542.240₫

25.542.240₫

25.542.240₫ - 25.542.240₫

25.542.240₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Signs Labels Identification / Labels Markers Printers / Desktop Printer Labels: Panduit H050X064H2T

MÔ TẢ SẢN PHẨM

The thermal transfer military grade heat-shrink label in yellow is single sided with a 3/8" (9.525mm) diameter and made of 3:1 flattened polyolefin. It is .5" (12.7mm) wide and .64" (16.3mm) high. The heat-shrink sleeve is designed to provide a clear, reliable, and durable way to identify wires and

_THÔNG SỐ KỸ THUẬT:

Product Type	Heat Shrink Label
Color	Yellow
Compatible Wire Gauge (AWG)	18
Diameter (In.)	0.38
Diameter (mm)	9.5
Material	Polyolefin
Flammability Rating	VW-1
Number of Labels	2000
Number of Labels per Row	4
Number of Sides	1
Maximum Operating Temperature (°C)	135
Maximum Operating Temperature (°F)	275
Minimum Operating Temperature (°C)	-55
Minimum Operating Temperature (°F)	-67
Overall Height (In.)	0.64
Overall Height (mm)	16.3
Overall Length (In.)	0
Overall Length (mm)	0
Overall Width (In.)	0.5
Overall Width (mm)	12.7
Resistance Properties	Military Grade
Standards Met	(1) Meets UL Standard 224 for flammability and AMS-DTL-23053/5C (Class 1 and Class 3) (2) Will meet MIL-M-81531, MIL-STD202F, and MIL-STD-883E when printed with RMH4BL or RHH4BL-S ribbons (3) RoHS Compliant
Sub Brand	Pan-Code®
Label Application	Cable & Wire Marking
Label Property	Flammability, Fluid Resistance, Harsh Environments, Military Grade
Printer Type	Thermal Transfer

The thermal transfer military grade heat-shrink label in yellow is single sided with a 3/8" (9.525mm) diameter and made of 3:1 flattened polyolefin. It is .5" (12.7mm) wide and .64" (16.3mm) high. The heat-shrink sleeve is designed to provide a clear, rel
