Panduit GCE1/0-1/0

Panduit E style grounding connector for #6 SOL – 1/0 STR (16 – 50mm²) for main and tap. [GCE1/0-1/0]; PAL620

Mã kho: PAL620
Mã nhà sản xuất: GCE1/0-1/0
Tên nhà sản xuất: Panduit
0₫ - 0₫
0₫
0₫ - 0₫
0₫
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Grounding Bonding / Grounding Compression Connectors Covers / E Style Connectors: Panduit GCE1/0-1/0

MÔ TẢ SẢN PHẨM

The GCE1/0-1/0 Style Grounding Connector is designed to enhance the crimp process using technology that meetings the IEEE Stud 837 – 2002. With wide range-taking ability and multi-conductor design provides flexibility with a minimum number of parts. The slotted design allows quick and easy assembly

_THÔNG SỐ KỸ THUẬT:

Sub Brand StructuredGround™
Connector Type E-Style Connector
Overall Length (In.) 0.94
Overall Length (mm) 23.9
Material High Conductivity Copper
Overall Width (In.) 0.66
Overall Width (mm) 16.8
Overall Height (In.) 1.72
Overall Height (mm) 43.7
Maximum Copper Conductor Size (AWG STR) 1/0
Minimum Copper Conductor Size (AWG SOL) 6
Panduit Die Index Number PG10
Color Code Red
Standards Met IEEE Std 837-2002, cULus listed, UL467, CSA 22.2
Application Utility/Ground Grid
Product Type E-Tap Grounding Connectors
