Panduit E style grounding connector for 1/0 STR – 250 kcmil (70 – 120mm²) main and tap. [GCE250-250]; PAL622

Name: Panduit E style grounding connector for 1/0 STR – 250 kcmil (70 – 120mm²) main and tap. [GCE250-250]; PAL622
Brand: Panduit
SKU: PAL622
Price: 1204660.0 VND
Availability: InStock

Mã kho: PAL622

Mã nhà sản xuất: GCE250-250

Tên nhà sản xuất: Panduit

1.204.660₫ - 1.204.660₫

1.204.660₫

1.204.660₫ - 1.204.660₫

1.204.660₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Grounding Bonding / Grounding Compression Connectors Covers / E Style Connectors: Panduit GCE250-250

MÔ TẢ SẢN PHẨM

The GCE250-250 E Style Grounding Connector is designed to enhance the crimp process using technology that meetings the IEEE Stud 837 – 2002. With wide range-taking ability and multi-conductor design provides flexibility with a minimum number of parts. The slotted design allows quick and easy assembl

_THÔNG SỐ KỸ THUẬT:

Sub Brand	StructuredGround™
Connector Type	E-Style Connector
Overall Length (In.)	1
Overall Length (mm)	25.4
Material	High Conductivity Copper
Overall Width (In.)	1.08
Overall Width (mm)	27.4
Overall Height (In.)	2.66
Overall Height (mm)	67.5
Maximum Copper Conductor Size (AWG STR)	250
Maximum Copper Conductor Size (kcmil)	250
Minimum Copper Conductor Size (AWG STR)	1/0
Maximum Ground Rod Size (In.)	5/8
Maximum Ground Rod Size (mm)	15.87
Minimum Ground Rod Size (In.)	1/2
Minimum Ground Rod Size (mm)	12.7
Maximum Rebar Size (In.)	1/2
Maximum Rebar Size (mm)	12.7
Minimum Rebar Size (In.)	3/8
Minimum Rebar Size (mm)	9.52
Panduit Die Index Number	PG25
Color Code	Black
Standards Met	IEEE Std 837-2002, cULus listed, UL467, CSA 22.2
Application	Utility/Ground Grid
Product Type	E-Tap Grounding Connectors
