Grounding Bonding / Grounding Compression Connectors Covers / E Style Connectors: Panduit GCE500-1/0

MÔ TẢ SẢN PHẨM

The GCE500-1/0 Style Grounding Connector is designed to enhance the crimp process using technology that meetings the IEEE Stud 837 – 2002. With wide range-taking ability and multi-conductor design provides flexibility with a minimum number of parts. The slotted design allows quick and easy assembly

_THÔNG SỐ KỸ THUẬT:

Sub Brand	StructuredGround™
Connector Type	E-Style Connector
Overall Length (In.)	1
Overall Length (mm)	25.4
Material	High Conductivity Copper
Overall Width (In.)	1.36
Overall Width (mm)	34.5
Overall Height (In.)	2.64
Overall Height (mm)	67
Maximum Copper Conductor Size (kcmil)	500
Minimum Copper Conductor Size (kcmil)	250
Maximum Ground Rod Size (In.)	3/4
Maximum Ground Rod Size (mm)	19.05
Minimum Ground Rod Size (In.)	1/2
Minimum Ground Rod Size (mm)	12.7
Maximum Rebar Size (In.)	3/4
Maximum Rebar Size (mm)	19.05
Minimum Rebar Size (In.)	5/8
Minimum Rebar Size (mm)	15.87
Panduit Die Index Number	PG50
Color Code	Blue
Standards Met	IEEE Std 837-2002, cULus listed, UL467, CSA 22.2
Application	Utility/Ground Grid
Product Type	E-Tap Grounding Connectors
