Panduit GCHE250-250

Panduit Heavy Duty Ground "E" Style Conn. 1/0 STR–250 kcmil (70–120mm²), 1/0 STR–250 kcmil (70–120mm²) [GCHE250-250]; PAL629

Mã kho: PAL629
Mã nhà sản xuất: GCHE250-250
Tên nhà sản xuất: Panduit
1.697.610₫ - 1.697.610₫
1.697.610₫
1.697.610₫ - 1.697.610₫
1.697.610₫
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Grounding Bonding / Grounding Compression Connectors Covers / E Style Connectors: Panduit GCHE250-250

MÔ TẢ SẢN PHẨM

Heavy Duty Ground "E" Style Conn. 1/0 STR–250 kcmil (70–120mm²), 1/0 STR–250 kcmil (70–120mm²)

_THÔNG SỐ KỸ THUẬT:

Note NA
Sub Brand NA
Connector Type E-Style Connector
Overall Length (In.) 1.08
Overall Length (mm) 27.4
Material High Conductivity Copper
Overall Width (In.) 1.88
Overall Width (mm) 47.6
Overall Height (In.) 2.66
Overall Height (mm) 67.6
Maximum Copper Conductor Size (AWG SOL) NA
Maximum Copper Conductor Size (AWG STR) NA
Maximum Copper Conductor Size (AWG) NA
Maximum Copper Conductor Size (kcmil) 250
Minimum Copper Conductor Size (AWG SOL) NA
Minimum Copper Conductor Size (AWG STR) 1/0
Minimum Copper Conductor Size (AWG) NA
Maximum Ground Rod Size (In.) 3/4
Maximum Ground Rod Size (mm) 19.1
Minimum Ground Rod Size (In.) 1/2
Minimum Ground Rod Size (mm) 12.7
Maximum Rebar Size (AWG) 6
Maximum Rebar Size (In.) 3/4
Maximum Rebar Size (mm) 19.1
Minimum Rebar Size (AWG) 3
Minimum Rebar Size (In.) 3/8
Minimum Rebar Size (mm) 9.5
Panduit Die Index Number PG25
Color Code Black
Standards Met cULus Listed to UL 467 for direct burial grounding applications iin earth or concrete. Meets IEEE837-2014 Standard with Enhanced Crimp Process.
Application Utility/Ground Grid
Product Type Grounding Heavy Duty E-Tap Grounding Connectors
