FLIR FLIR VT8 Clamp Meters, Max Current 200A ac, 200A dc CAT III 1000 V, CAT IV 600 V [VT8-1000]; 181-2427
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Absolute Maximum AC Current Measurement | 200A ac |
| Absolute Maximum DC Current Measurement | 200A dc |
| Absolute Maximum AC Voltage Measurement | 1000V ac |
| Absolute Maximum DC Voltage Measurement | 1000V dc |
| Absolute Maximum Resistance Measurement | 60MΩ |
| Model Number | VT8 |
| AC Current Measurement Resolution | 100mA |
| DC Current Measurement Resolution | 100mA |
| Best DC Current Accuracy | ±2.5 % |
| Clamp Meter Type | Multifunction Clamp |
| Best AC Current Accuracy | ±2.5 % |
| Best AC Voltage Accuracy | ±1 % |
| Best DC Voltage Accuracy | ±1 % |
| True RMS | Yes |
| Display Type | LCD |
| Maximum Operating Temperature | +50°C |
| Safety Category Voltage | 600 V, 1000 V |
| Battery Type | AA |
| Height | 53mm |
| Non-Contact Voltage Detector | Yes |
| Width | 35mm |
| AC Voltage Measurement Resolution | 100mV |
| Length | 210mm |
| Jaw Capacity Busbars | 15.5mm |
| Weight | 163.7g |
| Dimensions | 210 x 35 x 53mm |
| DC Voltage Measurement Resolution | 100mV |
| Functions Measured | AC Current, AC Voltage, Auto-Ranging, Capacitance, Continuity, Data Hold, DC Current, DC Voltage, DCA Zero, Non-Contact Voltage Detector (NCV), Relative Mode, Resistance, True RMS |
| Safety Category | CAT III 1000 V, CAT IV 600 V |
| Best Resistance Measurement Accuracy | ±1.5 % |
| Safety Category Level | CAT III, CAT IV |
| Power Source | Battery |
| Minimum Operating Temperature | -10°C |
