Hongfa Europe GMBH DPDT Non-Latching Relay PCB Mount, 12V dc Coil, 3 A, 3 A Subminiature DIP Relay [HFD2/012-S-D]; 176-2938
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 12 V dc |
| Coil Power | 150mW |
| Coil Resistance | 960 Ω |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Switching Current | 3A |
| Terminal Type | PCB Pin |
| Number of Poles | 2 |
| Maximum Switching Current AC | 0.125 |
| Maximum Switching Current DC | 0.125 |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 220V |
| Depth | 10.2mm |
| Series | HFD2 |
| Maximum Switching Power DC | 90 W |
| Length | 20.2mm |
| Maximum Switching Power AC | 125 VA |
| Height | 10.6mm |
