10 Way Preci-Dip Right Angle Through Hole 2.54mm SIL Socket, Solder, 3A 100 V ac, 150 V dc [399-87-110-10-003101]; 701-9650
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 10 |
| Contact Material | Beryllium Copper, Brass |
| Contact Plating | Gold, Tin |
| Pitch | 2.54mm |
| Orientation | Right Angle |
| Termination Method | Solder |
| Mounting Type | Through Hole |
| Housing Material | Glass Fibre Reinforced PCT |
| Current Rating | 3A |
| Voltage Rating | 100 V ac, 150 V dc |
| Dimensions | 25.4 x 2.95 x 2.54mm |
| Depth | 2.54mm |
| Length | 25.4mm |
| Maximum Operating Temperature | +125°C |
| Minimum Operating Temperature | -55°C |
| Width | 2.95mm |
