Panduit lugs [LCA10-38-L], PAD037
Panduit lugs [LCA10-38-L], PAD037

Panduit lugs [LCA10-38-L], PAD037

Mã kho: PAD037
Mã nhà sản xuất: LCA10-38-L
Tên nhà sản xuất: Panduit
18.510₫ - 18.510₫
18.510₫
18.510₫ - 18.510₫
18.510₫
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Termination / Lugs Splices Split Bolts Accessories / Mechanical & Compression Lugs & Splices: Panduit LCA10-38-L

MÔ TẢ SẢN PHẨM

One-hole, standard barrel with window lug, #10 AWG wire, 3/8 stud hole.

_THÔNG SỐ KỸ THUẬT:

Copper Conductor Size (AWG) #10
Copper Conductor Size (kcmil) 10.4
Product Type Tin-Plated Copper Compression Connectors - Lugs
Sub Brand Pan-Lug
Stud Hole Size (In.) 42.95
Stud Hole Size (mm) 9.5
Barrel Type Standard Barrel Length with Inspection Window
Barrel Length (In.) 0.38
Barrel Length (mm) 9.7
Tongue Type Standard
Tongue Width (In.) 0.56
Tongue Width (mm) 14.2
Tongue Angle Straight
Tongue Thickness (In.) 0.04
Tongue Thickness (mm) 1
Overall Length (In.) 1.38
Overall Length (mm) 35.1
Standards Met C22.2 No. 65-13, 486A-486B File #E52164
Wire Strip Length (In.) 42,552
Wire Strip Length (mm) 11.1
Part Features Tin plated to inhibit corrosion,color coded barrel,inspection window, NEBS level 3.
