Panduit lugs [LCAX2-14-E], PAC270
Panduit lugs [LCAX2-14-E], PAC270

Panduit lugs [LCAX2-14-E], PAC270

Mã kho: PAC270
Mã nhà sản xuất: LCAX2-14-E
Tên nhà sản xuất: Panduit
133.110₫ - 133.110₫
133.110₫
133.110₫ - 133.110₫
133.110₫
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Termination / Lugs Splices Split Bolts Accessories / Mechanical & Compression Lugs & Splices: Panduit LCAX2-14-E

MÔ TẢ SẢN PHẨM

The LCAX2-14-E Tin-Plated Copper Compression Lug, one-hole, standard barrel, has color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection. An inspection window aids to visually assure full conductor insertion, and the tin-plate material helps

_THÔNG SỐ KỸ THUẬT:

Inside Diameter (In.) 0.36
Inside Diameter (mm) 9.14
Outer Diameter (In.) 0.47
Outer Diameter (mm) 11.93
Product Type Tin-Plated Copper Compression Connectors - Lugs
Lug Type 1 Stud Hole Lug
Base Material Copper
Class G Copper Flex Conductor Size (AWG) 2
Class H Copper Flex Conductor Size (AWG) 2
Class I Copper Flex Conductor Size (AWG) 2
Class K Copper Flex Conductor Size (AWG) 2
Class M Copper Flex Conductor Size (AWG) 2
Copper Code Conductor Size (AWG) 2
DLO Copper Flex Conductor Size (AWG) 2
Sub Brand Pan-Lug™
Stud Hole Size (In.) 1/4
Stud Hole Size (mm) 6.4
Barrel Type Standard Barrel with Inspection Window
Barrel Length (In.) 0.59
Barrel Length (mm) 15
Tongue Type Standard
Tongue Width (In.) 0.7
Tongue Width (mm) 17.8
Tongue Angle Straight
Tongue Thickness (In.) 0.11
Tongue Thickness (mm) 2.8
Overall Length (In.) 1.5
Overall Length (mm) 38.1
Finish/Coating Tin-Plated
Standards Met C22.2 No. 65-13, 486A-486B File #E52164
UL Temperature Rating (°C) 90
Maximum Voltage (kV) 35
Color Code Brown
Panduit Die Index Number P33
Burndy Die Index Number 10
T & B Die Index Number 10
Wire Strip Length (In.) 11/16
Wire Strip Length (mm) 17.5
Part Features Tin plated to inhibit corrosion,color coded barrel,inspection window, beveled wire entry.
