Panduit lugs [LCAX3/0-38H-X], PAD318

Name: Panduit lugs [LCAX3/0-38H-X], PAD318
Brand: Panduit
SKU: PAD318
Price: 337400.0 VND
Availability: InStock

Mã kho: PAD318

Mã nhà sản xuất: LCAX3/0-38H-X

Tên nhà sản xuất: Panduit

337.400₫ - 337.400₫

337.400₫

337.400₫ - 337.400₫

337.400₫

One-hole, flex lug, 3/0 AWG wire, 3/8 stud hole, 45° angle tongue.

Product Type	Tin-Plated Copper Compression Connectors - Lugs
Sub Brand	Pan-Lug
Stud Hole Size (In.)	42.95
Stud Hole Size (mm)	9.5
Barrel Type	Standard Barrel Length with Inspection Window
Barrel Length (In.)	0.91
Barrel Length (mm)	23.1
Tongue Type	Standard Tongue Width
Tongue Width (In.)	1.06
Tongue Width (mm)	26.9
Tongue Angle	45°
Tongue Thickness (In.)	0.14
Tongue Thickness (mm)	3.6
Overall Length (In.)	1.85
Overall Length (mm)	47
Color Code	Orange
Panduit Die Index Number	P50
Burndy Die Index Number	14
Wire Strip Length (In.)	1
Wire Strip Length (mm)	25.4
Part Features	Tin plated to inhibit corrosion,color coded barrel,inspection window, beveled wire entry.
