Panduit lugs [LCCX4-14A-L], PAC957

Name: Panduit lugs [LCCX4-14A-L], PAC957
Brand: Panduit
SKU: PAC957
Price: 187390.0 VND
Availability: InStock

Mã kho: PAC957

Mã nhà sản xuất: LCCX4-14A-L

Tên nhà sản xuất: Panduit

187.390₫ - 187.390₫

187.390₫

187.390₫ - 187.390₫

187.390₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Termination / Lugs Splices Split Bolts Accessories / Mechanical & Compression Lugs & Splices: Panduit LCCX4-14A-L

MÔ TẢ SẢN PHẨM

The LCCX4-14A-L Tin-Plated Copper Compression Lug, two-hole, long barrel, has color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection. The long barrel maximizes the number of crimps and provides premium wire pull-out strength and performance.

_THÔNG SỐ KỸ THUẬT:

Inside Diameter (In.)	0.28
Inside Diameter (mm)	7.11
Outer Diameter (In.)	0.38
Outer Diameter (mm)	9.65
Product Type	Tin-Plated Copper Compression Connectors - Lugs
Lug Type	2 Stud Hole Lug
Base Material	Copper
Copper Code Conductor Size (AWG)	4
DLO Copper Flex Conductor Size (AWG)	4
Sub Brand	Pan-Lug™
Stud Hole Size (In.)	1/4
Stud Hole Size (mm)	6.4
Stud Hole Spacing (In.)	0.63
Stud Hole Spacing (mm)	16
Barrel Type	Long Barrel with Inspection Window
Barrel Length (In.)	1.05
Barrel Length (mm)	26.7
Tongue Type	Standard
Tongue Width (In.)	0.55
Tongue Width (mm)	14
Tongue Angle	Straight
Tongue Thickness (In.)	0.09
Tongue Thickness (mm)	2.3
Overall Length (In.)	2.49
Overall Length (mm)	63.2
Finish/Coating	Tin-Plated
Standards Met	C22.2 No. 65-13, 486A-486B File #E52164
UL Temperature Rating (°C)	90
Maximum Voltage (kV)	35
Color Code	Gray
Panduit Die Index Number	P29
Burndy Die Index Number	8
T & B Die Index Number	8
Wire Strip Length (In.)	1-1/8
Wire Strip Length (mm)	28.6
Part Features	Tin plated to inhibit corrosion,color coded barrel,inspection window, beveled wire entry.
