Gossen Metrawatt METRAHIT PM PRIME BT Handheld Digital Multimeter, 10A ac 600V ac 10A dc 600V dc [M248B]; 136-5804
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Multimeter Type | Handheld |
| Absolute Maximum AC Current Measurement | 10A ac |
| Absolute Maximum DC Current Measurement | 10A dc |
| Absolute Maximum Resistance Measurement | 30MΩ |
| Absolute Maximum DC Voltage Measurement | 600V dc |
| Absolute Maximum AC Voltage Measurement | 600V ac |
| Absolute Maximum Capacitance Measurement | 3mF |
| Absolute Maximum Temperature Measurement | +80 (Internal) °C, +100 (PT100) °C, +850 (PT1000) °C, +1372 (Type K) °C |
| Functions Measured | AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature |
| True RMS | Yes |
| Maximum Frequency | 1MHz |
| Display Type | LCD |
| Model Number p | METRAHIT PM PRIME BT |
| DC Current Measurement Resolution | 1nA dc |
| AC Current Measurement Resolution | 10nA ac |
| Resistance Measurement Resolution | 1mΩ |
| DC Voltage Measurement Resolution | 1µV dc |
| AC Voltage Measurement Resolution | 10µV ac |
| Capacitance Measurement Resolution | 1pF |
| Temperature Measurement Resolution | 0.1K |
| Length | 87mm |
| Width | 45mm |
| Safety Category Level | CAT III, CAT IV |
| Best AC Current Accuracy | 0.01 |
| Battery Type | 1.2 V NiMH, 1.5 V AA Alkaline Manganese LR6 |
| Safety Category Voltage | 300 V, 600 V |
| Dimensions | 87 x 45 x 200mm |
| Best DC Current Accuracy | 0.01 |
| Height | 200mm |
| Maximum Operating Temperature | +50°C |
| Best DC Voltage Accuracy | 0.01 |
| Best Temperature Measurement Accuracy | 0.01 |
| Best Resistance Measurement Accuracy | 0.01 |
| Battery Life | 200 h |
| Weight | 400 (with Battery)g |
| Best AC Voltage Accuracy | 0.01 |
| Best Capacitance Measurement Accuracy | 0.01 |
| Minimum Operating Temperature | -100°C |
