Contractor Products / Stainless Steel / Custom Strapping: Panduit IMS9.5T35-QR6L

MÔ TẢ SẢN PHẨM

Panduit® Pan-Steel® StrongHold™ Custom Strapping can be cut to meet your many project needs. Built with 316L stainless steel with a fold-over lock, it maintains a safe, secure connection despite severe weather, intense UV rays, high vibration and galvanic corrosion. Perfect for some of the most chal

_THÔNG SỐ KỸ THUẬT:

Application	Corrosive Environment
Product Type	Custom Length Stainless Steel Strapping
Color	Natural
Environment	Indoor and Outdoor
Finish/Coating	NA
For Use With	BT75SDT
Material	316 Stainless Steel
Maximum Installation Temperature (°C)	538
Maximum Installation Temperature (°F)	1000
Minimum Installation Temperature (°C)	-80
Minimum Installation Temperature (°F)	-112
Maximum Operating Temperature (°C)	538
Maximum Operating Temperature (°F)	1000
Minimum Operating Temperature (°C)	-60
Minimum Operating Temperature (°F)	-76
Minimum Loop Tensile Strength (N)	1780
Minimum Loop Tensile Strength (lb)	400.15
Overall Length (In.)	984.24
Overall Length (mm)	25000
Overall Width (In.)	0.37
Overall Width (mm)	9.5
Resistance Properties	UV-Resistant
Standards Met	RoHS Compliant
Sub Brand	StrongHold™
Strap Breaking Strength (N)	1780
Strap Breaking Strength (lb)	400.15
Minimum Bundle Width (In.)	1.02
Minimum Bundle Width (mm)	26
Overall Thickness (In.)	0.01
Overall Thickness (mm)	0.4
Part Features	Fold over design provides high-retained tension in mechanical fastening and cable bundling applications; After tensioning, cut end is locked inside low profile buckle – no sharp edges; For applications that require various bundle diameters; Supplied in reels of 100 ft (30.5 m); Uncoated; Provides job site versatility with minimum inventory; Packaging speeds removal of steel and includes bundle diameter cut off guide.
