Roxburgh EMC IHF Series 8A 480 V ac 60Hz Flange Mount RFI Filter, with Stud Terminals, Single Phase [IHF408]; 188-9163
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Current Rating | 8A |
| Maximum Voltage Rating | 480 V ac |
| Mounting Type | Flange Mount |
| Termination Style | Stud |
| Number of Phases | 1 |
| Series | IHF |
| Operating Frequency | 60Hz |
| Length | 230mm |
| Depth | 147mm |
| Capacitance | 1µF |
| Height | 55mm |
| Inductance | 1.4 mH |
| Dimensions | 230 x 147 x 55mm |
| Minimum Operating Temperature | -25°C |
| Leakage Current | 0.6 mA |
| Maximum Operating Temperature | +85°C |
| Resistance | 15mΩ |
| Standards Met | EN 60939 |
| Power Loss | 1W |
