Sensata / Crydom 5 A SPST Solid State Relay, Zero Cross, PCB Mount, SCR, 660 V rms Maximum Load [MCXE480D5]; 738-5575
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 0.06 A rms |
| Maximum Load Current | 0.208333333333333 |
| Mounting Type | PCB Mount |
| Minimum Load Voltage | 48 V rms |
| Maximum Load Voltage | 660 V rms |
| Minimum Control Voltage | 15 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Zero Cross |
| Contact Configuration | SPST |
| Terminal Type | Through Hole |
| Output Device | SCR |
| Package Style | SIP |
| Maximum Turn On Time | 1/2 cycle |
| Dimensions | 43.1 x 10.2 x 25.4mm |
| Maximum Operating Temperature | +80°C |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 → +80°C |
| Length | 43.1mm |
| Off State Leakage Current | 0.1 mA rms |
| Height | 25.4mm |
| Depth | 10.2mm |
| Control Voltage Range | 15 → 32 V dc |
| Load Voltage Range | 48 → 660Vrms |
