Sensata / Crydom 25 A Solid State Relay, Zero Crossing, Panel Mount, 280 Vrms Maximum Load [SMR2425-6]; 145-0606
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 40 Arms |
| Maximum Load Current | 25 A |
| Mounting Type | Panel Mount |
| Series | SMR24-6 |
| Minimum Load Voltage | 60 Vrms |
| Maximum Load Voltage | 280 Vrms |
| Minimum Control Voltage | 8 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Zero Crossing |
| Terminal Type | Screw |
| Maximum Turn On Time | 1/2 cycles |
| Dimensions | 45.7 x 58.4 x 24.2mm |
| Length | 45.7mm |
| Operating Temperature Range | -40 → +80°C |
| Minimum Operating Temperature | -40°C |
| Height | 24.2mm |
| Capacitance | 8pF |
| Maximum Operating Temperature | +80°C |
| Off State Leakage Current | 10 mArms |
| Number of Poles | 1 |
| Relay Type | Solid State Relay |
| Standards Met | CE |
| Load Voltage Range | 60 → 280Vrms |
| Control Voltage Range | 8 → 32 V dc |
| Depth | 58.4mm |
| Special Features | Alarm Output Signal, DC Control, Inverting Or Non-Inverting Input, LED Status Indicators, Normally Open Or Normally Closed Alarm Output |
