Dual saddle clip for fiber slack management and fiber patch cord routing. Accepts two cable bundles up to 1.06" dia (26.9mm) each. Nylon 6.6 material, black. Push mount into 0.18" (4mm) pre-drilled holes in Opticom® Fiber Enclosures.

Name: Dual saddle clip for fiber slack management and fiber patch cord routing. Accepts two cable bundles up to 1.06" dia (26.9mm) each. Nylon 6.6 material, black. Push mount into 0.18" (4mm) pre-drilled holes in Opticom® Fiber Enclosures.
Brand: Panduit
SKU: PAP595
Availability: InStock

Mã kho: PAP595

Tên nhà sản xuất: Panduit

0₫ - 0₫

0₫

0₫ - 0₫

0₫

📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Routing Management Protection / Cable Conduit Supports / Wire Saddles Standoffs Retainers: Panduit VWSDC-C20

MÔ TẢ SẢN PHẨM

Dual saddle clip for fiber slack management and fiber patch cord routing. Accepts two cable bundles up to 1.06" dia (26.9mm) each. Nylon 6.6 material, black. Push mount into 0.18" (4mm) pre-drilled holes in Opticom® Fiber Enclosures.

_THÔNG SỐ KỸ THUẬT:

Application	1) Use in Pre-Drilled .18 Inch (4.0Mm) Holes in Panels Up to .09 Inch (2.0Mm) Thick, (2) Smooth Rounded Edges Eliminate Potential for Snagging and Stress
Product Type	Wire Clip - Push Mount
Color	Black
Environment	Indoor
Material	Nylon 6.6
Mount Method	Push Barb
Resistance Properties	Flame Resistant
Standards Met	UL E136577, UL94V-2, RoHS Complaint
Maximum Bundle Diameter (In.)	1.06
Maximum Bundle Diameter (mm)	26.9
Standoff Height (In.)	2.37
Standoff Height (mm)	60.2
Overall Length (In.)	2.71
Overall Length (mm)	68.8
Overall Width (In.)	1.33
Overall Width (mm)	33.8

Dual saddle clip for fiber slack management and fiber patch cord routing. Accepts two cable bundles up to 1.06" dia (26.9mm) each. Nylon 6.6 material, black. Push mount into 0.18" (4mm) pre-drilled holes in Opticom® Fiber Enclosures.

MÔ TẢ SẢN PHẨM

_THÔNG SỐ KỸ THUẬT:
