| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Frequency Range Sinewave | 20MHz |
| Minimum Frequency Range Sinewave | 1mHz |
| Maximum Frequency Range Square Pulse and Arbitrary Waveform | 20MHz |
| Minimum Frequency Range Square Pulse and Arbitrary Waveform | 1 mHz |
| Maximum Frequency Range Triangle/Saw | 1MHz |
| Minimum Frequency Range Triangle/Saw | 1mHz |
| Digital Frequency | Yes |
| Digital Amplitude and Offset | Yes |
| Internal Linear and Log Sweep | Yes |
| Variable Sweep | Yes |
| Internal and External Amplitude Modulation | Yes |
| FM Modulation | Yes |
| Time Base Accuracy | ±10ppm |
| Plug Type | Type C - European Plug, Type G - British 3-pin |
| Input Impedance | 10 kΩ |
| Output Amplitude | 20V Pk-Pk |
| Length | 235mm |
| Frequency Range Square Pulse and Arbitrary Waveform | 1 mHz → 20 MHz |
| Maximum Operating Temperature | +40°C |
| Output Impedance | 50 Ω, 600 Ω |
| Width | 260mm |
| Model Number p | TG 2000 |
| Weight | 2kg |
| Height | 88mm |
| Dimensions | 235 x 260 x 88mm |
| Minimum Operating Temperature | +5°C |
| Interface Type | RS232, USB |
