Artesyn AEE20W-M 20W Isolated DC-DC Converter Through Hole, Voltage in 36 → 75 V dc, Voltage out 12V dc Medical [AEE02BB48-M]; 174-3807
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | ±12V dc |
| Input Voltage Range | 36 → 75 V dc |
| Input Voltage Nominal | 48 V dc |
| Isolation Voltage | 4.2kV dc |
| Power Rating | 20W |
| Output Current | 840mA |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Medical Approved | Yes |
| Efficiency | 0.89 |
| Package | 2 in x 1 in Case |
| Minimum Temperature | -40°C |
| Load Regulation | 0.01 |
| Maximum Temperature | +80°C |
| Width | 25.4mm |
| Series | AEE20W-M |
| Depth | 12mm |
| Standards Met | ANSI/AAMI ES60601-1, Class A, EMI EN55011, EMS EN60601-1-2, EN 55022, EN/IEC 60601-1, FCC, Level A |
| Length | 50.8mm |
