Block ultrasonic proximity sensor [U500.PA0.2-GP2J.72F]; 187-1799
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Detection Range | 70 → 1000 mm |
| Output Type | Push Pull |
| Body Style | Block |
| Thread Size | M12 x 1 |
| Transducer Frequency | 200 (Sonic)kHz |
| Communication Protocol | IO-LINK |
| Maximum DC Voltage | 30V |
| Supply Voltage | 12 → 30 V dc |
| Terminal Type | M12 Connector |
| IP Rating | IP67 |
| Housing Material | Plastic |
| Reverse Polarity Protection | Yes |
| Short Circuit Overload Protection | Yes |
| Switching Current | <100 (Output) mA |
| Dimensions | 56.2 x 32.2 x 18 mm |
| Maximum Operating Temperature | +65°C |
| Width | 32.2mm |
| Length | 56.2mm |
| Response Time | <40 ms |
| Depth | 18mm |
| Minimum Operating Temperature | -25°C |
| Interface | IO-Link |
| Standards Met | CE, CULus |
