Carling Technologies 150A 1 Pole Thermal Magnetic Circuit Breaker, 125 V dc, 277 V ac F [FA1-B0-14-815-12A-BG]; 881-1356
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Current Rating | 150A |
| Number of Poles | 1 |
| Series | F |
| Mounting Hole Size | 38.29 x 59.13mm |
| Application | Battery Disconnect Systems, Higher Amperage Applications, Ideal for Applications Under Extreme Temperatures, Military, Solar Power Systems |
| Mounting Hole Width | 59.1mm |
| Overall Length | 38.1mm |
| Breaking Capacity at Maximum Voltage Rating | 10000 A @ 277 V ac, 50000 A @ 125 V dc |
| Tripping Mechanism | Hydraulic-Magnetic |
| Mounting Style | Panel Mount |
| Overall Depth | 75.4mm |
| Terminal Contact Type | Stud |
| Special Features | AC ratings to UL489, Consistent Trip Point Over Temperatures Ranging From -40°C to +85°C, DC Voltage Ratings up to 700A with Metering Shunt Section, Optional 25 Millivolt Metering Shunt Construction |
| Overall Dimensions | 38.1 x 180.98 x 75.38mm |
| Reset Actuator Type | Handle |
| Mounting Hole Length | 38.3mm |
| Break Time | Short |
| Rated AC Voltage | 277V |
| Rated DC Voltage | 125V |
| Circuit Breaker Type | MCCB |
