Celduc 5 A Solid State Relay, Zero Cross, PCB Mount, 275 V ac Maximum Load [SKA10420]; 917-4719
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 1 mA |
| Maximum Load Current | 0.208333333333333 |
| Mounting Type | PCB Mount |
| Minimum Load Voltage | 12 V ac |
| Maximum Load Voltage | 275 V ac |
| Minimum Control Voltage | 2.5 V dc |
| Maximum Control Voltage | 10 V dc |
| Switching Type | Zero Cross |
| Terminal Type | PCB Pin |
| Package Style | SIP4 |
| Maximum Turn On Time | 10 ms |
| Dimensions | 43.2 x 10.2 x 25.4mm |
| Special Features | Very Low Zero Cross Voltage, Zero Cross Solid State Relay for Printed Circuit Board Designed for Most Types of Loads |
| Standards Met | CE, CULus Recognized, IEC/EN61000-4-4, IEC/EN61000-4-5, UL/VDE |
| Relay Type | AC |
| Control Voltage Range | 2.5 → 10 V dc |
| Load Voltage Range | 12 → 275V ac |
| Depth | 10.2mm |
| Height | 25.4mm |
| Off State Leakage Current | 0.1 mA |
| Length | 43.2mm |
| Operating Temperature Range | -40 → +100°C |
