Celduc 125 A Solid State Relay, Random, Panel Mount, Thyristor, 690 V ac Maximum Load [SO789060]; 917-4790
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 5 mA |
| Maximum Load Current | 125 A |
| Mounting Type | Panel Mount |
| Minimum Load Voltage | 25 V ac |
| Maximum Load Voltage | 690 V ac |
| Minimum Control Voltage | 3.5 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Random |
| Terminal Type | Screw |
| Output Device | Thyristor |
| Maximum Turn On Time | 0.1 ms |
| Dimensions | 45 x 58.5 x 30mm |
| Length | 45mm |
| Operating Temperature Range | -55 → +100°C |
| Special Features | Green LED Visualization on The Input, IP20 Protection by Removable Flaps on Terminals with Optional Labels, Over-Voltage Protection |
| Relay Type | AC |
| Standards Met | CE Certified, CULus Recognized |
| Height | 30mm |
| Off State Leakage Current | 1 mA |
| Control Voltage Range | 3.5 → 32 V dc |
| Load Voltage Range | 25 → 690V ac |
| Depth | 58.5mm |
