Celduc 25 A Solid State Relay, Zero Cross, Panel Mount, Thyristor, 280 V ac Maximum Load [SO942860]; 917-4816
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 5 mA |
| Maximum Load Current | 25 A |
| Mounting Type | Panel Mount |
| Minimum Load Voltage | 12 V ac |
| Maximum Load Voltage | 280 V ac |
| Minimum Control Voltage | 10 V dc, 15 V ac |
| Maximum Control Voltage | 30 V dc, 32 V ac |
| Switching Type | Zero Cross |
| Terminal Type | Screw |
| Output Device | Thyristor |
| Maximum Turn On Time | 10 ms |
| Dimensions | 44.8 x 59.4 x 30mm |
| Control Voltage Range | 10 → 30 V dc, 15 → 32 V ac |
| Load Voltage Range | 12 → 280V ac |
| Depth | 59.4mm |
| Relay Type | AC |
| Special Features | Green LED Visualization on The Input, IP20 Protection By Removable Flaps on Terminals with Optional Labels, Zero Cross Solid State Relay Especially Designed for Resistive Loads |
| Operating Temperature Range | -55 → +100°C |
| Length | 44.8mm |
| Height | 30mm |
| Off State Leakage Current | 1 mA |
