Cornell-Dubilier 15000μF 35V dc Aluminium Electrolytic Capacitor, Through Hole 25 x 50mm +85°C 25mm 10mm 50mm [380LX153M035J052]; 871-3909
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 15000 µF |
| Voltage | 35 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 25 x 50mm |
| Length | 50mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 25mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 1000 (Shelf) h, 3000 (Endurance) h |
| Lead Pitch | 10mm |
| Series | 380LX |
| Ripple Current | 5.6 A @ 120 Hz, 6.4 A @ 20 kHz |
| Tolerance | ±20% |
| Equivalent Series Resistance | 27 mΩ @ 20 kHz, 36 mΩ @ 120 Hz |
