Cornell-Dubilier 680μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 35 x 45mm +85°C 35mm 10mm 45mm [381LQ681M400A452]; 871-4283
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 680 µF |
| Voltage | 400 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 35 x 45mm |
| Length | 45mm |
| Minimum Operating Temperature | -25°C |
| Diameter | 35mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 10mm |
| Lifetime | 1000 (Shelf) h, 2000 (Load) h, 8000 (Ripple) h |
| Series | 381LQ |
| Ripple Current | 2.12 A @ 120 kHz, 2.97 A @ 20 kHz |
| Tolerance | ±20% |
| Equivalent Series Resistance | 121 mΩ @ 20 kHz, 268 mΩ @ 120 kHz |
