Cornell-Dubilier 270μF 200V dc Aluminium Electrolytic Capacitor, Through Hole 20 x 35mm +105°C 20mm 10mm 35mm [381LX271M200G032]; 871-4303
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 270 µF |
| Voltage | 200 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 20 x 35mm |
| Length | 35mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 20mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 1000 (Shelf) h, 12000 (Ripple) h |
| Lead Pitch | 10mm |
| Series | 381LX |
| Tolerance | ±20% |
| Ripple Current | 1.1 A @ 120 Hz, 1.5 A @ 20 kHz |
| Equivalent Series Resistance | 376 mΩ @ 20 kHz, 737 mΩ @ 120 Hz |
