Cornell-Dubilier 330μF 450V dc Aluminium Electrolytic Capacitor, Through Hole 35 x 40mm +105°C 35mm 10mm 40mm [381LX331M450A042]; 871-4243
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 330 µF |
| Voltage | 450 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 35 x 40mm |
| Length | 40mm |
| Minimum Operating Temperature | -25°C |
| Diameter | 35mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 10mm |
| Lifetime | 1000 (Shelf) h, 12000 (Ripple) h |
| Series | 381LX |
| Equivalent Series Resistance | 410 mΩ @ 20 kHz, 804 mΩ @ 120 Hz |
| Ripple Current | 1.4 A @ 120 Hz, 2 A @ 20 kHz |
| Tolerance | ±20% |
