Cornell-Dubilier 390μF 200V dc Aluminium Electrolytic Capacitor, Through Hole 22 x 30mm +105°C 22mm 10mm 30mm [381LX391M200H022]; 871-4182
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 390 µF |
| Voltage | 200 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 22 x 30mm |
| Length | 30mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 22mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 1000 (Shelf) h, 12000 (Ripple) h |
| Lead Pitch | 10mm |
| Series | 381LX |
| Tolerance | ±20% |
| Equivalent Series Resistance | 260 mΩ @ 20 kHz, 510 mΩ @ 120 Hz |
| Ripple Current | 1.3 A @ 120 Hz, 1.8 A @ 20 kHz |
