Cornell-Dubilier 1000μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 50.8 (Dia.) x 92.08mm +105°C 50.8mm [550C102T400BJ2B]; 744-1701
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1000 µF |
| Voltage | 400 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 50.8 (Dia.) x 92.08mm |
| Height | 92.08mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 50.8mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 22.23mm |
| Lifetime | 10000h |
| Series | 500C |
| Equivalent Series Resistance | 94.2mΩ |
| Leakage Current | <=3√CV μA @ 5 min, 4 mA @ 5 min (Maximum) |
| Tolerance | -10 → +50% |
| Ripple Current | 6.6A |
