Cornell-Dubilier 10μF 16V dc Aluminium Electrolytic Capacitor, Surface Mount 3 x 5.3mm +85°C 3mm 0.8mm 5.3mm [AVE106M16A12T-F]; 871-3779
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 10 µF |
| Voltage | 16 V dc |
| Mounting Type | Surface Mount |
| Technology | Electrolytic |
| Dimensions | 3 x 5.3mm |
| Length | 5.3mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 3mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 0.8mm |
| Lifetime | 1000 (Shelf) h, 2000 h |
| Series | AVE |
| Leakage Current | 0.01 CV or 3 μA |
| Polarised | Polar |
| Tolerance | ±20% |
| Equivalent Series Resistance | 33.16 Ω @ 120 Hz/+20°C |
| Ripple Current | 14 mA @ 120 Hz/+85°C |
| Dissipation Factor | 0.2 % @ 120 Hz/+20°C |
