Cornell-Dubilier 10μF 35V dc Aluminium Electrolytic Capacitor, Surface Mount 5 x 5.3mm +85°C 5mm 1.5mm 5.3mm [AVE106M35C12T-F]; 871-3785
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 10 µF |
| Voltage | 35 V dc |
| Mounting Type | Surface Mount |
| Technology | Electrolytic |
| Dimensions | 5 x 5.3mm |
| Length | 5.3mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 5mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 1000 (Shelf) h, 2000 h |
| Lead Pitch | 1.5mm |
| Series | AVE |
| Ripple Current | 34 mA @ 120 Hz/+85°C |
| Tolerance | ±20% |
| Polarised | Polar |
| Leakage Current | 0.01 CV or 3 μA |
| Dissipation Factor | 0.12 % @ 120 Hz/+20°C |
| Equivalent Series Resistance | 19.89 Ω @ 120 Hz/+20°C |
