Cornell-Dubilier 1000μF 10V dc Aluminium Electrolytic Capacitor, Surface Mount 10 x 10mm +85°C 10mm 3.1mm 10mm [AVE108M10G24T-F]; 871-3877
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1000 µF |
| Voltage | 10 V dc |
| Mounting Type | Surface Mount |
| Technology | Electrolytic |
| Dimensions | 10 (Dia.) x 10mm |
| Length | 10mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 10mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 3.1mm |
| Lifetime | 1000 (Shelf) h, 2000 h |
| Series | AVE |
| Leakage Current | 0.01 CV or 3 μA |
| Dissipation Factor | 0.24 % @ 120 Hz/+20°C |
| Polarised | Polar |
| Equivalent Series Resistance | 400 mΩ @ 120 Hz/+20°C |
| Tolerance | ±20% |
| Ripple Current | 458 mA @ 120 Hz/+85°C |
