Cornell-Dubilier 3000μF 450V dc Aluminium Electrolytic Capacitor, Panel Mount 76.2 (Dia.) x 92.08mm +85°C 76.2mm [DCMC302T450DJ2B]; 744-1688
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 3000 µF |
| Voltage | 450 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 76.2 (Dia.) x 92.08mm |
| Height | 92.08mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 76.2mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 2000h |
| Lead Pitch | 31.75mm |
| Series | DCMC |
| Leakage Current | =6CV μA @ 5 min, 6 mA @ 5 min (Maximum) |
| Equivalent Series Resistance | 52.2mΩ |
| Tolerance | -10 → +50% |
| Ripple Current | 8.7A |
