Cornell-Dubilier 330μF 250V dc Aluminium Electrolytic Capacitor, Chassis Mount 51 x 44 x 13mm +125°C 25.4mm 51mm [MLS331M250EA0C]; 872-0285
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 330 µF |
| Voltage | 250 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 51 x 44 x 13mm |
| Height | 13mm |
| Length | 51mm |
| Depth | 44mm |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +125°C |
| Lead Pitch | 25.4mm |
| Lifetime | 2000h |
| Series | MLS |
| Equivalent Series Resistance | 262 mΩ @ 20 kHz, 399 mΩ @ 120 Hz |
| Ripple Current | 5 A @ 120 Hz, 6.3 A @ 20 kHz |
| Leakage Current | ≤0.002 CV μA |
| Tolerance | ±20% |
