Cornell-Dubilier 2200μF 63V dc Aluminium Electrolytic Capacitor, Through Hole 25 (Dia.) x 30mm +105°C 25mm 10mm [SLP222M063C3P3]; 744-1259
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 2200 µF |
| Voltage | 63 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 25 (Dia.) x 30mm |
| Height | 30mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 25mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 3000h |
| Lead Pitch | 10mm |
| Series | SLP |
| Equivalent Series Resistance | 136mΩ |
| Tolerance | ±20% |
| Leakage Current | <=3√CV μA @ 5 min |
| Ripple Current | 2.5A |
