Cornell-Dubilier 330μF 450V dc Aluminium Electrolytic Capacitor, Through Hole 35 (Dia.) x 35mm +105°C 35mm 10mm [SLP331M450H5P3]; 744-1332
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 330 µF |
| Voltage | 450 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 35 (Dia.) x 35mm |
| Height | 35mm |
| Minimum Operating Temperature | -25°C |
| Diameter | 35mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 10mm |
| Lifetime | 3000h |
| Series | SLP |
| Ripple Current | 2.01A |
| Leakage Current | <=3√CV μA @ 5 min |
| Tolerance | ±20% |
| Equivalent Series Resistance | 754mΩ |
