Deltron KMF Series 18A 500 V ac 60Hz Flange Mount EMI Filter, with Terminal Block Terminals 3 Phase [KMF318A]; 761-5801
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Current Rating | 18A |
| Maximum Voltage Rating | 500 V ac |
| Mounting Type | Flange Mount |
| Termination Style | Terminal Block |
| Number of Phases | 3 |
| Series | KMF |
| Operating Frequency | 60Hz |
| Length | 229mm |
| Depth | 56mm |
| Height | 115mm |
| Dimensions | 229 x 56 x 115mm |
| Minimum Operating Temperature | -25°C |
| Leakage Current | 7.2 mA |
| Maximum Operating Temperature | +100°C |
| Resistance | 11.4mΩ |
| Standards Met | UL 1283 |
| Power Loss | 3.7W |
