DiodesZetex 74HCT04S14-13, Hex Schmitt Trigger, 3 State Inverter, 2 → 6 V, 14-Pin SOIC [74HCT04S14-13]; 122-2835
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Logic Function | Inverter |
| Input Type | Schmitt Trigger |
| Output Type | 3 State |
| Number of Elements per Chip | 6 |
| Schmitt Trigger Input | Yes |
| Maximum Propagation Delay Time @ Maximum CL | 265 ns @ 50 pF |
| Maximum High Level Output Current | -4mA |
| Maximum Low Level Output Current | 7.8mA |
| Mounting Type | Surface Mount |
| Package Type | SOIC |
| Pin Count | 14 |
| Logic Family | HCT |
| Dimensions | 8.74 x 3.99 x 1.48mm |
| Height | 1.48mm |
| Maximum Operating Supply Voltage | 6 V |
| Length | 8.74mm |
| Propagation Delay Test Condition | 50pF |
| Maximum Operating Temperature | +125 °C |
| Minimum Operating Supply Voltage | 2 V |
| Minimum Operating Temperature | -40 °C |
| Width | 3.99mm |
