DiodesZetex AP2171SG-13, Dual Power Distribution Switch, High Side, 110mΩ, 2.7 V min. 6-Pin, U-DFN2018 [AP2171SG-13]; 921-0420
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Switch Type | High Side |
| Number of Outputs | 2 |
| Switch On Resistance | 110mΩ |
| Maximum Power Dissipation | Internally Limited |
| Mounting Type | Surface Mount |
| Package Type | U-DFN2018 |
| Pin Count | 6 |
| Current Limit | 1.9A |
| Dimensions | 1.87 x 2.07 x 0.555mm |
| Length | 1.87mm |
| Width | 2.07mm |
| Height | 0.555mm |
| Maximum Input Voltage | 5.5 V |
| Maximum Operating Temperature | +85 °C |
| Minimum Output Current | 0A |
| Minimum Operating Temperature | -40 °C |
| Minimum Input Voltage | 2.7 V |
